2008 Lambotghini Gallardo Superleggera Twin Turbo -

Underground Racing Race version Twin Turbo System
1000 WHP using Pump Gas
1500+ WHP using Race Gas
• Custom twin billet 67mm turbochargers
• Tial billet wastegates
• Tial billet blow off valves
• Custom fabricated 3.5" stainless steel exhaust using aircraft quality metal
• Ultra lightweight stainless steel mufflers
• Exhaust Finish Options: high temp heat coating or polished mirror finish
• Custom fabricated stainless steel air induction using aircraft quality metal
• K&N air filters
• High quality silicone hose
• High pressure T •bolt clamps for intake pressure tubes
• High quality v •band clamps for exhaust connections
• Custom heat shielding and high quality heat wrap
• Custom Air/Water intercooler system with high flow water pump
• High flow intercooler water heat exchanger
• Custom ice water reservoir
• Show quality polishing on turbo compressor, intercooler and charge piping.
• Crankcase ventilation system

Underground Custom Billet Short Block
• Full blue print and balanced race short block
• Disassemble complete Lamborghini V10
• Install custom block sleeves
• Seat sleeves for aluminum block
• Bore & hone V10 with torque plate
• Machine block deck surface V10 Aluminum
• Machine block deck surface V10 Sleeves
• Balance complete V10 rotating assembly
• Mallory for balancing crankshaft
• Polish and mic crankshaft
• Jet clean block
• Jet clean cylinder heads
• Carrillo billet rods
• CP custom reverse dish race pistons
• CP spiral locks
• CP .180+ wall wrist pins
• CP oil rail support
• Custom steel cylinder sleeves
• Main bearings
• Rod bearings
• Total seal TNT file fit rings
• Assemble complete Lamborghini V10

Cylinder Head
• Race Version head port and polish
• Custom ARP L19 Lamborghini cylinder head studs

Fuel System
• Custom billet fuel pump hanger with high flow fuel pumps
• Custom aluminum fuel rails
• All Aeroquip stainless steel fuel line and aluminum fittings
• Aeromotive adjustable fuel pressure regulator
• Upgraded fuel injectors

Clutch
• Tilton Carbon race clutch
• Flywheel
• Pressure plate

Transmission
• Billet 1-6
• Billet final drive gears (Top speed aprox 225)
• Billet case work

Tuning
• Motec Engine Management System
• Custom wiring harness
• Professional dyno and streetability tuning
• Boost by gear

Tires
• Toyo tires
